Material Characteristics

Material Mix Permeability Material Density (g/cm2) Curie Temp.(¢XC) Temperature Stability (¢XC) Colour Code
-26 75 6.7 >=250 825 Yellow/White
-52 75 6.7 >250 650 Green/Blue

Cores Specification (Micrometals Equ)

Part Nbr AL nH/N2 AL nH/N2 OD (mm) ID (mm) Ht (mm) l (mm) A (cm2) V (cm3)
T030-26K 33.5 30.5 7.80 3.84 3.25 1.84 0.060 0.110
T037-26K 28.5 26.0 9.53 5.21 3.25 2.31 0.064 0.147
T044-26K 37.0 35.0 11.20 5.82 4.04 2.68 0.099 0.226
T050-26K 33.0 33.0 12.70 7.70 4.83 3.19 0.112 0.358
T050-26B 43.5 43.5 12.70 7.70 6.35 3.19 0.148 0.471
T060-26K 50.0 47.0 15.20 8.53 5.94 3.74 0.187 0.699
T068-26K 43.5 40.0 17.50 9.40 4.83 4.23 0.179 0.759
T068-26A 58.0 54.0 17.50 9.40 6.35 4.23 0.242 1.03
T068-26D 87.0 80.0 17.50 9.40 9.53 4.23 0.358 1.52
T080-26K 46.0 42.0 20.20 12.6 6.35 5.14 0.231 1.19
T080-26B 71.0 63.0 20.20 12.6 9.53 5.14 0.347 1.78
T090-26K 70.0 64.0 22.90 14.0 9.53 5.78 0.395 2.28
T094-26K 60.0 57.0 23.90 14.2 7.92 5.97 0.362 2.16
T106-26K 93.0 95.0 26.90 14.5 11.1 6.49 0.659 4.28
T130-26K 81.0 79.0 33.00 19.8 11.1 8.28 0.698 5.78
T131-26K 116.0 108.0 33.00 16.3 11.1 7.72 0.885 6.84
T150-26K 96.0 89.0 38.40 21.5 11.1 9.38 0.887 8.31
T157-26K 100.0 99.0 39.90 24.1 14.5 10.10 1.06 10.70
T184-26K 169.0 159.0 46.70 24.1 18.0 11.20 1.88 21.00
T200-26K 92.0 92.0 50.80 31.8 14.0 13.00 1.27 16.40
T225-26K 98.0 92.0 57.20 35.7 14.0 14.60 1.42 20.70

Tolerance

Part Nbr OD ID Ht
T030~T068 ¡Ó0.5mm ¡Ó0.5mm ¡Ó0.5mm
T080~T225 ¡Ó0.5mm ¡Ó0.5mm ¡Ó0.6mm

Note: please contact us if your size is not listed above***

¡@
